    20W 30 Watts Portable Handheld Metal Fiber Laser Marking Marker Machine for Metal Plastic PVC

    Ask Lasest Price
    Brand Name : Pefect Laser
    Model Number : PEDB-161
    Certification : CE / ISO / SGS / TUV
    Price : Negotiable
    Payment Terms : L/C,T/T,Western Union
    Supply Ability : 800 sets per month
    Delivery Time : 7-10 Working Days
    • Product Details
    • Company Profile

    20W 30 Watts Portable Handheld Metal Fiber Laser Marking Marker Machine for Metal Plastic PVC

    20W 30 Watts Portable Handheld Metal Fiber Laser Marking Marker Machine for Metal Plastic PVC


    Model: PEDB-161


    Machine Introduction


    Perfect Laser’s portable handheld laser marking machine incorporates programmable hardware and advanced DA integrated circuits to enable fast and precise laser targeting and operation. Built with optical coupling isolation, this system ensures dependable performance, low power usage, and steady functionality. Compact and lightweight, it's ideal for marking on a wide range of metals and select tough plastic surfaces.


    20W 30 Watts Portable Handheld Metal Fiber Laser Marking Marker Machine for Metal Plastic PVC


    Machine Features


    1. This portable laser marking machine uses a rugged industrial-grade plastic enclosure, effectively shielding it from water and dust in harsh production environments.

    2. Its streamlined, space-saving structure and easy-to-navigate interface make operation simple even for first-time users.

    3. Outfitted with a dual-axis maglev scan head, it ensures swift engraving speed, high accuracy, and a smaller footprint.

    4. The laser module is built for durability, offering extended service life without the need for routine upkeep.

    5. Featuring a high-sensitivity touch panel, intelligent positioning via red light guidance, and a powerful control system, the device delivers consistent and efficient results.

    6. Whether you're working on level surfaces or angled areas, this machine allows for flexible use in virtually any setting.

    7. The portable laser marking machine supports engraving diverse content types, from multilingual text and branding to visual elements like logos, barcodes, and QR codes.

    8. Its rechargeable lithium battery allows cordless operation for 6 to 8 hours, with extended standby of up to 12 hours, ensuring on-the-go usability.



    Application


    Compatible with a wide range of materials, including stainless steel, mild steel, carbon steel, iron, aluminum, zinc, and copper. The portable laser marking machine also supports marking on curved surfaces and rigid plastics.

    20W 30 Watts Portable Handheld Metal Fiber Laser Marking Marker Machine for Metal Plastic PVC


    Technical Data


    Product Name

    Handheld Portable Fiber Laser Marking Machine

    Model No.

    PEDB-161(Power version)

    PEDB-161-1(Battery version)

    Machine Material

    Engineering plastic

    Laser type

    Fiber Laser

    Laser Power

    20W/30W

    Laser Wavelength

    1064nm

    Marking Method

    High-precision 2D Scanning Method

    Marking Speed

    ≤7000mm/s

    Main Control Board

    Highly integrated main board

    with embedded 7-inches screen

    Maximum pulse energy

    0.75mJ

    Adjustable frequency range

    30-60kHZ

    Operating System

    Linux

    Cooling Method

    Air Cooling

    Marking Line Type

    Dot matrix + Vector all-in-one machine

    (both dot matrix and vector)

    Mirror Size

    Standard configuration8.5mm

    Marking Area

    50×50mm(Standard configuration)

    /100×100mm(Optional selection)

    Position Method

    Red light positioning

    Number of engraved character lines

    Any line within the marking range

    Marking Speed

    650 characters/second

    (the specific speed is related to the material

    & marking content)

    Font Support

    English / Korean / Russian / Arabic / Chinese

    numerals and other standard fonts

    (only choose one of above)

    File Format

    BMP / DXF / HPGL / JPEG / PLT

    Barcode / QR code

    CODE39, CODE128, CODE126, EAN13, PDF417,

    01CODE, QR, AZTECCODE, DM, GS1DM, DOTCODE, HANX INCODE

    Power Supply

    220V

    /

    Battery capacity

    /

    12 ampere hours

    Maximum Power Consumption

    ≤200W

    /

    The usage time was measured at an ambient temperature of 22 ℃

    /

    ≤7hours

    Full charge time

    /

    4 hours

    Net Weight (Host+control box)

    7.8KG

    8.4KG

    Control box size

    310mm×260mm×307mm

    Handheld size

    325mm×79mm×151mm

    241.5mm×79mm×151mm

    Class of pollution

    2

    Over voltage category

    II

    Temperature

    0-40℃

    Ambient Relative Humidity

    30%-85% RH

    Training & After Sales Service

    VCD training + 24 hours after-sales service

    Warranty

    36 month for fiber laser source

    24 month for whole machine



    Packaging & Delivery


    1. Prompt deliver at the very day.
    2. Sophisticated and professional logistic agent.
    3. Well-trained and disciplined packing team.
    4. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.



    Competitive Advantages


    1. We offer high quality products at competitive price in quick delivery.
    2. 100% custom pass guaranteed.
    3. Good after-sale service.
    4. Flexible and Untraceable payment terms.
    5. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
