30W Mini Desktop Nonmetallic Material Wood Leather GlassCo2 Laser
Marking Machine
(Model -PEDB-C30A)
※ Product Introduction
Perfect laser's CO2 desktop laser marking machine, mainly for
non-metal marking and marking of some metal materials.
It uses the RF metal laser tube as the laser source, the equipment
has a long service life. Marking is not limited by the site, and
with high.operation efficiency.
The overall structure of the product is more lightweight, portable,
easy to operate and maintain. The CO2 desktop laser marking machine
can be matched with different power lasers and field mirrors to
meet the marking needs of different formats and marking depths.
※ Product Features
1. The CO2 laser marking machine uses an RF metal laser tube as the
laser source, with a lifespan of 30000 to 40000 hours without
maintenance;
2. The CO2 laser marking machine has good beam quality, more stable
and precise, smoothly marking;
3. The CO2 laser marking machine can complete image scanning and
exquisite marking in a very short time using high-speed scanning
lenses.
4. Automatic fixtures and loading and unloading production lines
can be configured according to user requirements. Can automatically
complete date and serial number, and can mark strip type codes;
5. The co2 laser marker adopts mechanical moving parts with simple
structure, wear resistance, and corrosion resistance, making the
system have good stability and high motion accuracy;
6. The co2 laser marker can operate at full load for 24 hours,
meeting the requirements of the production party for large-scale
production;
7. Environmentally friendly and green, it is a labeling solution
for environmental protection;
8. The software have merits of easy operation, friendly interface,
workers can quickly get started;
9. Desktop CO2 is more lightweight and portable, simple and easy to
operate.
※ Application
Applicable Industry:
The CO2 laser marking machines are widely used for marking and
cutting graphics and text in the fields of clothing, leather, food
and beverage packaging, electronic components, handicrafts, glass
and stone processing.
Applicable Materials:
The CO2 laser marking machine is suitable for marking most
non-metal materials, such as paper packaging, plastic products,
label paper, leather fabric, glass ceramics, resin plastic, bamboo
and wood products, PCB board, etc. It can also cut thin fabrics,
cardboard and acrylic.
※ Sample shows
※Technical Data
| Model | 30W Wood Leather Nonmetallic Material Mini Desktop Co2 Laser Marking Machine |
| Control system | JCZ brand EZCAD |
| Marking depth | 0.01-0.3mm (adjustable according to material) |
| Line width: | 0.015mm |
| Marking speed | 7000mm/s |
| Marking format | 110*110mm |
| Repetition accuracy | ≤0.01mm |
| Laser wavelength | 1064nm |
| Marking function | Flat, cylindrical objects, fillable marks |
| Tag content | English, numbers, punctuation, Chinese, arbitrary graphics, bar
codes, etc |
| Laser power | 20W/30W(Optional) |
| Electricity demand | AC(110-220V)±10%,50/60Hz |
| Working environment | Temperature 15 ~ 35℃, humidity 45 ~ 75%, no dust, no oil smoke, no
corrosive gas |
| Software function | 1) Compatible software: CorelDRAW, AutoCAD, Photoshop, etc 2) Supported formats: PLT, DXF, BMP, JPGE, etc 3) Own word library: SHX, TTF Supported functions: text, graphics, pictures, automatic coding,
printing serial number, batch number, date, bar code,
two-dimensional code, automatic jump number, etc. |
