5W Intelligent Rechargeable Small Portable Handheld Laser Marker
for Packaging Wood Ear Tag
(Model:PEDB-30)
►Product Introduction
Perfect Laser PEDB-30 portable laser engraver with mobile battery is small in size, does not take up space, Using only one hand can pick up the laser engraving machine., convenient to carry. The portable laser engraver is simple to operate, no consumables, marking function is powerful. With removable battery, no need to connect the socket all the time, can be easily used. It is lightweight design, easy to carry out, cost-effective.
►Product Features
1. The handheld laser marker is suitable for all kinds of
materials, Marking range is large and marking content is rich, not
only can be marked separately, such as marking Chinese, English,
numbers,symbols,pictures,dates, two-dimensional code, bar code, but
also a number of content combination of personalized design can be
marked.
2. Flash marking, complete in seconds, greatly shortening the time
of batch marking. Equipped with multi-core automotive
industrial-grade processor, marking is clearer and faster.
3. Strong flexibility, according to the different material and
marking needs, can be personalized to adjust the laser intensity,
speed, fine carving fine peck each complex works.
4. The handheld laser marker using aperture positioning, accurate
marking, previewing the marked content before marking, reducing
mistakes.
5. The handheld laser marker comes with removable battery, can be
used without socket, and can be moved and marked at anytime and
anywhere.
6. Compact and portable, one hand can complete all operations,
lightweight design,the size of small, one hand can be lifted, take
away, edit, mark the slightest effort.
7. Easy to operate, easy to learn and easy to use, 5 inch HD touch
screen design, function keys at a glance, simple editing can be
marked.
►Technical Data
| Product Name | 5W Intelligent Rechargeable Small Portable Handheld Laser Marker
PEDB-30 |
| Laser Type | Semiconductor |
| Laser Wavelength | 460nm |
| Laser Power | 5W |
| Number of Marking Lines | Unrestricted |
| Font | 12 Fonts (Can be Defined Fonts) |
| Coding Range | 50*50mm |
| User Interface | Industrial Touch Screen Supports Simplified Chinese, Traditional
Chinese, English, Japanese and Other Languages. |
| Operating System | Linux |
| Beam Transmission | Down |
| Material | Stainless Steel and High-end Composite Materials |
| Cooling System | Air Cooling |
| Operating Temperature | 5-45℃ (41-113°F) |
| Operating Humidity | Max.95% RH, No Condensation |
| markContent | Words, Letters, Numbers, Symbols, QR Codes, Bar Codes, Pictures,
Dates, etc |
| marking Material | Metal Plate, Wood Products, Plastic, Plate, Cardboard and Other
Materials |
| Weight | 2.5 KG |
| Dimension | 207*66*208mm |
►Application
1. Applicable materials
The handheld laser etcher can mark wood, plastic, metal, plate,
cardboard and other common materials.
2. Applicable Industries
The handheld laser etcher is widely used in packaging, home,
construction, manufacturing and household DIY industries.
